Purpose
This dual-function machine is designed to train both the abdominal and lower back muscles in one compact unit. With adjustable support rollers and an ergonomic design, it ensures correct posture, comfort, and safety—ideal for core strengthening, injury prevention, and balanced full-body training in professional gym settings.
Dimensions & Technical Data:
Length: 1040 mm
Width: 1100 mm
Height: 1485 mm
Machine weight: 200.6 kg
Maximum load: 110 kg (weight stack)
Braided steel cable: 5 mm thick
50 mm elevated frame structure
Manual adjustment system with yellow-coded levers
Weight indicators in 3 colors
Mechanical Specifications:
Cam system delivers smooth, consistent resistance
Magnetized plate selector for quick and secure load changes
Designed for dual motion: abdominal crunch and back extension
Rounded tube construction supports ergonomic alignment
Visual instruction panel assists with proper usage
Comfort Features:
Adjustable support rollers ensure correct positioning
Vertical seat adjustment for personalized setup
Injection-core seat and back support maintain shape and comfort
Anti-bacterial dual-layer polyurethane foam upholstery
Optional multi-position handlebar
Non-slip handgrips for added security
Construction:
Heavy-duty steel frame with anti-corrosive electrostatic powder coating
Protective front and rear cowls for durability and safety
Chrome fittings and rubber details reduce vibration and noise
Connectivity:
Optional SmartFocus console for advanced workout tracking
Compatible with RFID access system
10" 4K LCD screen with multi-language support
Internet connectivity and guided tutorials via SmartFocus
Installation:
Delivered fully assembled or in modular parts depending on transport needs
Certification:
Built to European safety and quality standards for commercial gym environments
Warranty:
Welded frame: Lifetime
Mechanical parts: 3 years
Cables: 2 years
Upholstery and soft components: 1 year
End
