Purpose
The L070B Chest Press is engineered to isolate the major pectoral muscles, supporting balanced and aesthetic muscle development in the upper body. Its vertical push motion mimics free weight training while ensuring controlled movement, making it ideal for users of all levels, including rehabilitation and performance enhancement contexts.
Dimensions & Technical Data:
Length: 1480 mm
Width: 1330 mm
Height: 1485 mm
Machine weight: 235.3 kg
Standard weight stack: 110 kg
Optional weight stack: 125 kg
Braided steel cable: 5 mm thick
50 mm elevated structure for ease of cleaning and stability
Manual adjustment system with yellow-coded controls
Weight indicators in 3 colors
Easy-access frame design
Mechanical Specifications:
Cam-based resistance system for consistent load
Magnetized plate selector for quick weight adjustments
Isolateral kit option for independent arm training
Optional pneumatic seat adjustment
Integrated instructional graphic panel
Comfort Features:
Multi-position handlebar (optional) for grip variation
Injection-core seat and backrest with vertical adjustment
Dual-layer anti-bacterial upholstery for comfort and hygiene
Ergonomic padding for reduced joint stress
Non-slip handgrips for added safety during pressing motion
Construction:
Reinforced steel frame with corrosion-resistant powder coating
Electrostatic enamel finish available in matte or gloss
Rounded tube design improves safety and visual appeal
Front and rear cowls protect internal components and reduce noise
Connectivity:
SmartFocus console compatibility (optional)
10" LCD 4K display with multilingual interface
RFID user access for personalized sessions
Internet connectivity for performance tracking and tutorials
Installation:
Delivered fully assembled or in modular parts for easy transport
Certification:
Designed in accordance with European standards for commercial gyms
Warranty:
Welded frame: Lifetime
Mechanical parts: 3 years
Cable system: 2 years
Upholstery and soft parts: 1 year
End
Purpose
The L070B Chest Press is engineered to isolate the major pectoral muscles, supporting balanced and aesthetic muscle development in the upper body. Its vertical push motion mimics free weight training while ensuring controlled movement, making it ideal for users of all levels, including rehabilitation and performance enhancement contexts.
Dimensions & Technical Data:
Length: 1480 mm
Width: 1330 mm
Height: 1485 mm
Machine weight: 235.3 kg
Standard weight stack: 110 kg
Optional weight stack: 125 kg
Braided steel cable: 5 mm thick
50 mm elevated structure for ease of cleaning and stability
Manual adjustment system with yellow-coded controls
Weight indicators in 3 colors
Easy-access frame design
Mechanical Specifications:
Cam-based resistance system for consistent load
Magnetized plate selector for quick weight adjustments
Isolateral kit option for independent arm training
Optional pneumatic seat adjustment
Integrated instructional graphic panel
Comfort Features:
Multi-position handlebar (optional) for grip variation
Injection-core seat and backrest with vertical adjustment
Dual-layer anti-bacterial upholstery for comfort and hygiene
Ergonomic padding for reduced joint stress
Non-slip handgrips for added safety during pressing motion
Construction:
Reinforced steel frame with corrosion-resistant powder coating
Electrostatic enamel finish available in matte or gloss
Rounded tube design improves safety and visual appeal
Front and rear cowls protect internal components and reduce noise
Connectivity:
SmartFocus console compatibility (optional)
10" LCD 4K display with multilingual interface
RFID user access for personalized sessions
Internet connectivity for performance tracking and tutorials
Installation:
Delivered fully assembled or in modular parts for easy transport
Certification:
Designed in accordance with European standards for commercial gyms
Warranty:
Welded frame: Lifetime
Mechanical parts: 3 years
Cable system: 2 years
Upholstery and soft parts: 1 year
End
Download the Chest Press L070B Spec Sheet
Get all the technical details and specifications in one place. Download the PDF Spec Sheet below to explore dimensions, features, and performance data.
