Inertia Lat Pulldown Machine L110B

Purpose
The L110B is a professional lat pulldown machine engineered to develop the upper and central fibers of the latissimus dorsi. It enables effective back strengthening while also engaging the shoulders, biceps, and forearms. With ergonomic seating and smooth cable motion, it’s ideal for commercial gym environments focused on upper body development.

Dimensions & Technical Data:

• Length: 1450 mm

• Width: 1270 mm

• Height: 1980 mm

• Machine weight: 250.3 kg

• Standard weight stack: 110 kg

• Optional weight stack: 125 kg

• Braided steel cable: 5 mm diameter

• 50 mm elevated frame for hygiene and structural stability

• Easy Access design for better user entry/exit

• Yellow-coded manual adjustments for intuitive use

• Weight indicators in 3 colors

Mechanical Specifications:

• Cam system ensures consistent resistance throughout the movement

• Magnetized selector pin for safe and easy weight changes

• Pulley system optimized for smooth cable travel

Comfort Features:

• Optional multi-position handlebars for grip versatility

• Ergonomic injection-core seat and adjustable thigh support

• Anti-bacterial, dual-layer upholstery for comfort and hygiene

• Manual seat height adjustment

• Non-slip handgrips for secure workout control

Construction:

• High-grade steel frame with anti-corrosive powder coating

• Rounded tubing with premium welds

• Front and rear protective cowls for safety

• Available in various matte or gloss finishes

Connectivity:

• Optional SmartFocus console with full workout tracking

• 10" 4K LCD screen with multilingual support (25+ languages)

• RFID login and exercise tutorials

Installation:

• Delivered assembled or in modular format for convenient transport

Certification:

• Complies with commercial-grade European fitness equipment standards

Warranty:

• Welded frame: Lifetime

• Mechanical parts: 3 years

• Cable system: 2 years

• Upholstery and soft components: 1 year
